• Engine: 65 HP, 2400 RPM, 3 Cylinders, Rotary FIP, Coolant cooled with overflow reservoir, Turbo charged
• Air Filter: Dry type, Dual element
• Transmission: 9 Forward + 3 Reverse speed, Collarshift Gearbox
• Hydraulics: Lifting Capacity 2000 kgf at lower link ends
| Specs & Compare | ||||
|---|---|---|---|---|
| John Deere 5065E 5065E Utility Tractor |
| Type | 65 HP, 2400 RPM, 3 cylinder, | |||
|---|---|---|---|---|
| Airfilter | Dry type, dual element |
| Clutch | Dual | |||
|---|---|---|---|---|
| Gear Box | 9 Forward + 3 Reverse, Collar shift (Optional : TSS, Creeper) | |||
| Speeds | Forward 2.21 to 31.17 kmph, Reverse 3.58 to 24.12 kmph |
| Self-adjusting, self-equalizing, hydraulically actuated oil immersed disc brakes |
|
|---|
| Lifting Capacity | 1800 kg at lower link ends | |||
|---|---|---|---|---|
| 3 Point linkage | Category – II | |||
| Automatic depth & draft control |
|
| Type | Power |
|---|
| Type | Independent, 6 splines | |||
|---|---|---|---|---|
| RPM | 540 @ 2376 ERPM |
| Front | 6.5 x 20 2WD, 11.2x24 4WD | |||
|---|---|---|---|---|
| Rear | 18.4 x 30 2WD, 16.9x30 4WD |
| 68 litres |
|
|---|
| 100Ah, 12 volt battery 40 Amp. alternator 12 Volt, 2.5 kW starter motor |
|
|---|
| Total Weight | 2290 kg 2WD, 2425 kg 4WD | |||
|---|---|---|---|---|
| Wheel Base | 2050 mm | |||
| Overall length | 4026 mm | |||
| Overall width | 1901 mm | |||
| Ground clearance | 487 mm 2WD, 378 mm 4WD |
Product features are based on published information at the time of publication. Product features are subject to change without notice. Contact your local John Deere dealer for more information.
*Beginning 9/1/2016 all 5E Series Utility Tractors purchased new from an authorized John Deere Dealer come standard with a 5 year/2000 hour (whichever comes first) Powertrain Warranty. See the Limited Warranty for New John Deere Turf & Utility Equipment at dealer for details.
